Electro-Harmonix Percolator Harmonic Saturator Fuzz / Overdrive

🚚 FAST & FREE SHIPPING from Phoenix, AZ!

🎸 Local demo available by appointment in Phoenix, AZ

Electro-Harmonix EHX Percolator Harmonic Saturator Fuzz Pedal

A highly interactive transistor drive and fuzz that moves from raw, dynamic breakup to gated, pseudo-octave destruction.

Professor’s Notes

The Percolator fills the space between overdrive and fuzz without sounding like a conventional version of either. It can be chewy, sharp, sputtery, explosive, or surprisingly responsive—and the Bias control makes the transition between those personalities part of the instrument.

Rig Role

Second-Stage Escalation / Character Drive

The Percolator works especially well after a familiar low- or medium-gain foundation, taking an established core tone somewhere more aggressive, harmonically complex, and fuzz-adjacent.

Some fuzz pedals deliver one dominant sound, while many overdrives smooth out the rough edges that make a part interesting. The EHX Percolator instead offers a wider range of unstable, character-heavy gain—from lightly broken transistor drive to gated fuzz and pseudo-octave textures—without requiring a complicated control layout. As a second-stage drive, it does more than simply add gain: it introduces grind, compression, upper-harmonic bite, and, at more extreme Bias settings, deliberately gated or octave-like textures. Use it to make choruses feel larger, give leads a rougher edge, or push a controlled rhythm sound into something more aggressive and unstable.

It can also function independently as a raw transistor drive or full fuzz, but its clearest role is as a more distinctive second stage escalation drive.

Description

Inspired by the cult-classic Harmonic Percolator circuit of the 1970s, the Electro-Harmonix Percolator expands the original concept with a practical set of modern controls.

The Harmonics knob controls input gain, moving from dynamic overdrive into increasingly saturated fuzz. Bias changes the operating character of the gain circuit: lower settings produce smoother drive and distortion, while higher settings introduce pseudo-octave overtones, sputter, and gated decay. Balance controls the overall output level.

The Drive/Fuzz toggle changes the basic clipping structure. Drive mode removes the clipping diodes for a raw, chewy transistor-drive response. Fuzz mode engages the diodes for heavier saturation and more aggressive fuzz textures.

An internal trim pot adjusts overall gain and the range of the pseudo-octave response. The pedal also includes a latching/momentary footswitch: tap it for normal on/off operation, or press and hold for temporary bursts of fuzz or momentary bypass.

Quick Start Settings

Raw Transistor Drive
Drive mode
Harmonics: 10–11 o’clock
Bias: 9–10 o’clock
Balance: Set slightly above unity

Open, crunchy, and responsive. Start here for an unconventional overdrive sound that retains pick attack.

Explosive Fuzz
Fuzz mode
Harmonics: 2–3 o’clock
Bias: Noon–1 o’clock
Balance: Set to taste

A thick but articulate fuzz with more edge and harmonic movement than a typical sustaining fuzz circuit.

Gated and Sputtery
Fuzz mode
Harmonics: 2 o’clock or higher
Bias: 3 o’clock or higher
Balance: Compensate as needed

Use higher Bias settings for broken, gated decay and aggressive texture. Adjust Harmonics and Bias together to tune the response to your pickups.

Pseudo-Octave Texture
Fuzz mode
Harmonics: High
Bias: Around 2–3 o’clock

Play higher on the neck and experiment with the neck pickup for more pronounced octave-like overtones.

Specifications

• Effect type: Harmonic saturator / transistor overdrive / fuzz

• Circuit: Analog

• Audio: Mono

• Controls: Balance, Harmonics, Bias

• Toggle switch: Drive / Fuzz

• Bypass: Mechanical-relay true bypass

• Footswitch operation: Latching or momentary

• Internal adjustment: Gain and pseudo-octave range trim pot

• Input impedance: 70kΩ

• Output source impedance: 0–12.5kΩ, dependent on Balance setting

• Power: 9V battery or optional 9.6VDC center-negative adapter

• Current draw: 10mA

• Dimensions: 4.5" × 2.75" × 2.1"

• UPC: 683274012773
